Capacitor Panels

Get a Price/Quote

MOQ : 1 Piece

Capacitor Panels Specification

Components
Capacitor banks, APFC relay, MCB/MCCB, Contactor, Busbar, Fuses, Indicator Lamps, Auxiliary Devices

Current Rating
Up to 630A

Rated Current
250A

Cooling System
Natural Air Ventilation

Rated Insulation Voltage
690 V

Rated Operation Voltage
415 V

Panel Type
Floor Mounted

Operating Voltage
415 V AC

Cover Material
Mild Steel with Powder Coating

Protection Level
IP42 / IP54

Control System
Automatic with Microprocessor based Controller

Way
3 Phase

Features
Heavy-duty construction, High reliability, Easy installation, Low maintenance

Cabinet Material
CRCA Sheet Metal

Protection Class
Class 1

Thickness
1.6mm - 2mm

Base Material
Mild Steel Sheet

Connectivity Type
Wired

Product Type
Automatic Power Factor Correction (APFC) Panel

Material
Mild Steel (MS)

Surface Finish
Powder Coated

Standard
IS: 8623 / IEC 60439

Surface Color
Grey

Rated Voltage
415 V AC

Frequency (MHz)
50 Hz

Maximum Output Current
630A

Dimension (L*W*H)
Customizable as per requirement

Application
Industrial Power Factor Correction

IP Rating
IP42 / IP54

Display Type
LED Digital Display

Ambient Humidity
Up to 95% RH (non-condensing)

Earthing
Dual Earthing Provision

Operating Temperature Range
-10C to +50C

Busbar Material
Electrolytic Grade Copper / Aluminum

Terminals
Heavy Duty Cable Entry with Gland Plate

Mounting Type
Floor Standing / Wall Mounting (optional)

Panel Weight
Depends on Design & kVAR rating

Panel Make
OEM/Customized

Enclosure Type
Dust and Vermin Proof

Capacitor Capacity
Varies from 5 kVAR to 600 kVAR

Power Loss
<2.0W per kVAR

Capacitor Panels Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Pieces Per Month

Delivery Time
07 Days

Main Domestic Market
Maharashtra

Capacitor Panels About

Introducing our sizzling range of Capacitor Panels, the top-ranking solution engineered for towering industrial efficiency. With a rarefied capacity spectrum from 5 kVAR to 600 kVAR and heavy-duty OEM/customized builds, these panels are available in both floor-standing and wall-mounting options. Featuring robust mild steel enclosures, copper/aluminum busbars, and dual earthing, their dust- and vermin-proof designs ensure max protection. Reserve your unit now-limited stock available for quick dispatch! Elevate your facility's power factor correction with unparalleled reliability, tailored dimensions, and advanced microprocessor controls.

Versatile Applications: Industrial & Commercial Sectors

Capacitor Panels are implemented across a wide swath of industries and commercial spaces demanding efficient power factor correction. Ideal for manufacturing units, corporate complexes, malls, and heavy-duty engineering sites, these panels optimize electrical usage in diverse application media, from process industries to infrastructure projects. Their adaptability ensures seamless integration in every site environment, promoting energy efficiency and operational excellence across India's varied industrial landscape.

Swift Delivery, Flexible Payments & Hassle-Free Sampling

Every ordered Capacitor Panel is professionally handed over for dispatching within pre-agreed timelines, with sample units available for on-site evaluation. Outlays are streamlined, offering straightforward payment terms tailored for commercial convenience. Our delivery networks ensure timely panel installation, no matter your location, simplifying your procurement and deployment process while maintaining our high standards of service quality and responsiveness.

FAQ's of Capacitor Panels:

Q: How do Capacitor Panels benefit industrial power factor correction?

A: Capacitor Panels automatically optimize power consumption, reducing losses and improving overall electrical system efficiency. This leads to lower energy bills and enhanced operational reliability in industrial environments.

Q: What is the process for customizing a Capacitor Panel to meet specific facility needs?

A: Our panels are fully customizable based on your kVAR requirements, dimensions, and mounting preferences. After sharing your specifications, our engineering team designs the optimal configuration to suit your application.

Q: Where can these Capacitor Panels be installed?

A: Our panels are suitable for a variety of settings, including factories, commercial complexes, and process industries. They can be mounted on floors or walls and are designed to withstand harsh industrial conditions.

Q: When can I expect delivery after placing my order?

A: Once your order and payment terms are finalized, the panel is handed over for dispatching as per our agreed schedule, ensuring swift and reliable delivery across India.

Q: What maintenance is required for these Capacitor Panels?

A: These panels are crafted for minimal maintenance, thanks to their dust-proof, vermin-proof enclosures and heavy-duty construction. Routine inspections and cleaning suffice for long-term performance.
