MCC Panels

Get a Price/Quote

MOQ : 1 Piece

MCC Panels Specification

Rated Current
Upto 1600A

Components
Air Circuit Breakers, Contactors, Overload Relays, MCCBs, Switches, Indicators

Features
Modular construction, High reliability, Fully compartmentalized, Easy maintenance

Cooling System
Natural/Forced Air Ventilation

Rated Insulation Voltage
660V

Panel Type
Floor Mounted

Connectivity Type
Cable Entry Top/Bottom

Protection Level
IP55

Operating Voltage
380-415V AC

Thickness
2 mm

Base Material
Mild Steel

Rated Operation Voltage
415V AC

Cover Material
Mild Steel with Powder Coating

Cabinet Material
Powder-Coated Mild Steel

Way
Multi Way

Protection Class
Class I

Current Rating
Upto 1600A

Control System
Manual/Automatic

Product Type
MCC Panel

Material
Mild Steel (MS)

Surface Finish
Powder Coated

Standard
IEC 61439-1/2, IS 8623

Surface Color
Siemens Grey

Rated Voltage
415V AC

Frequency (MHz)
50 Hz

Maximum Output Current
1600A

Dimension (L*W*H)
As per client requirement / Customizable

Application
Industrial Motor Control

IP Rating
IP55

Display Type
Analog/LED Indicating Lights

Wiring
Neatly Dressed and Numbered Ferruling

Degree of Protection
IP42, IP54, IP55 as per requirement

Operation Mode
Local/Remote

Incoming Cable Entry
Top / Bottom Entry

Busbar Material
Electrolytic Grade Aluminum/Copper

Panel Door
Gasketed with Lock & Key Arrangement

Phase Indication
Provided with R, Y, B indicators

Ambient Temperature
-10C to +45C

Interlocking
Mechanical and Electrical Interlocking Possibility

Control Voltage
110V / 230V AC

Neutral Bar
Full-size Neutral Bar Provided

Earthing
Full length earth bus provided

Mounting Type
Free Standing / Floor Mounted

Short Circuit Withstand Capacity
Up to 50kA for 1 sec

MCC Panels Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Pieces Per Month

Delivery Time
07 Days

Main Domestic Market
Maharashtra

MCC Panels About

Experience a phenomenal Price Cut on our top-of-the-line MCC Panels, engineered specifically for superior industrial motor control applications. Crafted using electrolytic grade aluminum or copper busbars, these glorious panels provide transcendent performance with short circuit withstand capacity up to 50kA for 1 second. Enjoy advanced features like full-size neutral and earth bars, modular construction, IP55-rated protection, and custom dimensions. Hot deal includes neatly dressed wiring, reliable mechanical and electrical interlocking, and Siemens grey powder-coated finish. Suitable for both manual and automatic operations, these MCC panels assure safety, versatility, and easy maintenance for diverse industrial needs.

Versatile Usage & Expansive Applications

Our MCC Panels are a top choice for operating and controlling motors in numerous industries, including manufacturing plants, process industries, and utilities. These panels excel in both local and remote environments, thanks to their robust design and advanced protection features. Additionally, they can be used in infrastructure projects, commercial buildings, and any application requiring reliable motor control, seamless connectivity, and maximum operational efficiency. Their modularity ensures a perfect fit for various custom industrial applications.

Packaging, Sample Policy & Export Markets

When you request a quotation, our team ensures stock-ready MCC Panels with secure packaging tailored to prevent transit damage. Benefit from our sample policy that facilitates product assessment before bulk purchase, ensuring confidence in quality at the lowest price. With streamlined export logistics, we serve major markets across Asia, Africa, and the Middle East, consistently delivering value and reliability to our international clients. Choose us for transparent deals and swift, safe delivery every time.

FAQ's of MCC Panels:

Q: How do MCC Panels enhance safety in industrial motor control applications?

A: MCC Panels incorporate mechanical and electrical interlocking, IP55 protection rating, and full compartmentalization, creating a secure and reliable solution that minimizes operational hazards for personnel and equipment.

Q: What is the process for customizing MCC Panels to meet client-specific dimensions?

A: Clients can specify their required dimensions during the quotation process. Our engineering team collaborates closely with you to design and manufacture MCC Panels tailored precisely to your application and space requirements.

Q: Where are these MCC Panels most commonly used?

A: These MCC Panels are predominantly utilized in industrial settings such as manufacturing plants, process industries, utilities, and infrastructure projects where dependable motor control and robust protection are essential.

Q: What are the main benefits of using electrolytic grade aluminum or copper busbars in MCC Panels?

A: Electrolytic grade aluminum or copper busbars provide excellent conductivity and durability, resulting in superior energy efficiency, minimal losses, and extended operational life for your MCC Panels.

Q: How is maintenance managed with these MCC Panels?

A: The panels are fully compartmentalized and feature neatly dressed, numbered wiring, making routine inspections, troubleshooting, and maintenance straightforward and efficient for technicians.
